DC Motor Driver BTS7960 Single Channel 43A

DescriptionBTS7960B H-bridge 43A high-power motor driverModule (For Single Motor). This driver uses Infineon chips BTS7960 composed of high-power drive full H-bridge driver module with thermal over-current protection.Double BTS7960 H-bridge driver circuit, with a strong drive and braking, effectively isolating the microcontroller and motor driver! High-current 43AFeatures:Double BTS7960 large current (43 A) H bridge driver.5V isolate with MCU, and effectively protect MCU.5V power indicator on board.Input supply voltage 5.5V to 27V.Voltage indication of motor driver output end.Built-in heat sink.Just need four lines from MCU to the driver module (GND. 5V. PWM1. PWM2).Able to reverse the motor forward, two PWM input frequency up to 25kHZ.Two heat flows pass through an error signal output.Isolated chip 5V power supply (which can be shared with the MCU 5V), can also use the on-board 5V supply.APPLICATIONSDC motor driver4WD high-power mobile robot platformCombat robotsPumpsElectric fansConveyors

Dimensions

measures approx. (external, L x W x H):

130mm x 130mm x 10mm
